• Multi IR/AC Control Pages
• 8 slave +1 Master HVAC (FCU\AHU)
• Clapper Mic Sensor Built in
• IR Eye Built in (Receive Hand Held Remote control commands)
• Lux Sensor Built in (Light Intensity Adjustment according to sun light)
• PIR Motion Sensor Built in (For Energy Saving Occupancy, and Security)
• 2Z (NO\NC) DI
• IR Emitters (Flashers) with 255 IR cod s menus
• Logic 32 tables ×8 lines
• Security 99 codes
• LED (RGB) Surround Wall Effect
• Menu buttons on top modified for easy use
• Blue Back lit Buttons
• Built in temp sensor thermostat
      Added Logic Condition
            - If temp
            - If lux
            - If occupancy
• Slim Elegant Design
• Fruit Basket Finishes and Variety of Materials and Patterns to fit any Decor
• Fits most Wall Back Box Standards: (UK, Germany, France, Australia,USA, South Africa and Other)
• Trail Click Ready (Simply Add any TC Module to Back of DDPs.
• S-wave compatible
• Ceiling Fan Speed Control Added
• Password / Code Entry Feature Added

WHY G4 (GENERATION-4) IS BETTER? DDP, FDP, 6B, 4B, 3B

Under Construction

Q. If the customer wants to stop the shutter in the middle, how it can be done? Must use logic?
A. If you would like to add the function of stopping shutter, you don't need make the logic. You can do the programming as following:
Make one button on DDP as the function of stopping shutter:
Button Mode: Combination off,
Button configuration: suppose to you are using CH 1 & CH 2 as shutter, make ch1 & Ch2 both off

Q. How to Backup the Device
A. Go to Menu Backup, Device Backup

Q: DDP menu is not organised it does not run in order it jumps like page 1, music, AC, Heating, Page 2, 3 & 4
A: We designed them like that. DDP has 7 pages in total, 3 of them are fixed page(Music,AC,floor heating), 4 of them are dynamic page ( from 1 to 4). The default page is page 1, press left button it will go to Music, press right button it will go to AC, Since there 3 page are most often to use.

Q: The songs from the SD Card are not getting updated in the DDP's music page it shows playlist empty. Also the smart cloud software doesn't show all the songs that were originally present in the SD Card it only shows a few of them
A: 1 - They Must Change SD card Type. Use only Original Kingstone and SanDisk.
2 - Use only xxx.mp3 (Proper format of Mp3 Only)
3 - The Albums Must be only one Level
Example: E:\Boudhabar\zzzz.mp3
E:\Hindi\xxxx.mp3
E:\Hindi\yyyy.mp3
X,y,z are song names example only

Under Construction

• SmartBUS Product Catalogue
• DDPs Flyer
• Installation Manual
• Programming Manual
• DDP Scene Recording
• SmartBUS General System Diagram

Softwares and Firmwares

• Smart Cloud Software Versions
• Upgrade Kit Driver (Win 7 & XP)
• SmartBus DDP Firmware v1.37
• JTAG Firmware Upgrade

Control Applications

Lighting, HVAC, security, motorized shades, music, moods and scenes, fountains, irrigation, gates, LED color, service request, panic, code entry, lifts, media equipment...etc.
